57 56
HI 3210B/5 BNC connector, 5 m (16.5') cable, double junction, Pt, plas-
tic body, PVDF junction, polymer-filled
GOLD ORP ELECTRODES
HI 4932B/5 BNC connector, 5 m (16.5') cable, double junction, Au, plastic
body with built-in amplifier and external thread
ELECTRODES FOR HIGH PRESSURE APPLICATIONS
pH ELECTRODES
½‘’ thread, double PVDF junction, polymer filled, max operating pressure of 6 bar (87
psi)
Part Code Matching Pin Amplifier Connector Cable
HI 1002/3 NO NO BNC 3 m (10’)
HI 1002/5 NO NO BNC 5 m (16.5’)
HI 1003/3 YES NO BNC* 3 m (10’)
HI 1003/5 YES NO BNC* 5 m (16.5’)
HI 1004/5 YES YES spade lugs* 5 m (16.5’)
* In addition to the electrode connector, there is also a spade lug connection for the
matching pin
PLATINUM ORP ELECTRODES
HI 3090T Screw connector, external PG13.5 thread, double junction,
Pt, glass body, polymer filled
HI 3210T Screw connector, external PG13.5 thread, double junction,
Pt, plastic body, cloth junction
HI 3211T Screw connector, external PG13.5 thread, double junction,
Pt, plastic body, PVDF junction, polymer-filled
HI 2930B/5 BNC connector, 5 m (16.5') cable, double junction, Pt, plas-
tic body with built-in amplifier and external thread, cloth
junction
HI 2931B/5 BNC connector, 5 m (16.5') cable, double junction, Pt, plas-
tic body with built-in amplifier and external thread, PVDF
junction, polymer-filled
HI 3090B/5 BNC connector, 5 m (16.5') cable, double junction, Pt, glass
body, polymer-filled
