8

When the input reading is unstable.
When the stirrer is on.
Temperature warning (only if the “Temperature compensation” is disabled). The
warning symbol will be displayed if the temperature difference between the temperature of
the sample confirmed at the first step and the subsequent readings is greater than 3 °C.

Measure screen

Press ESC at any moment during the measurement cycle and

the instrument will return to the main screen.

Press Pause to pause the measurement process.

Press Stir to start/stop the stirrer.

If the difference between the temperature of the sample

confirmed at the first step and the subsequent readings is

greater than 3°C and the temperature compensation feature is

disabled in Setup, the temperature warning icon will blink

and the message “WARNING: Large temperature change!”

will be displayed.

Main screen display

Press Setup to acces the instrument’s setup.

Press RCL to view logged data.

Press Start to begin a new measurement cycle.

Press HELP at any moment to view the contextual help.

Measure screens

Icons from the stirrer and reading status area

GUIDE TO DISPLAY CODES

During the instrument’s operation a series of informations are displayed on the LCD.

1) current time information area
2) instrument status area
3) functional keys area
4) stability criteria
5) stirrer and reading status area

Conditioning screen

A two minutes conditioning period is initiated.

Press Continue to stop the conditioning period and skip the

message.
