Model UV232A-4S and UV232A-8S

6

2.3 Trigger Button Operation

The UV232A-4S and UV232A-8S splitters have a front panel “REMOTE TRIGGER”
button used to tell each remote URA-232 or URA-232-XT receivers to send a pre-
configured serial string that is stored in the receiver.

Note
Ensure that all receivers connected to the splitter are setup for “Remote Button
Trigger
” operation using the software GUI for proper operation.

2.4 Remote Trigger Command Operation

The UV232A-4S and UV232A-8S splitters can be remotely triggered from the RS-
232 source via specific serial commands. Upon receiving the appropriate command,
each receiver will send a pre-configured serial string that is stored in the receiver.

Note
Ensure that all receivers connected to the splitter are setup for “Remote Command
Trigger
” operation using the software GUI for proper operation.
