Model UV232A-4S and UV232A-8S
16
5. Specifications
Video
Gain
Unity
Number/signal type 1 analog signal input. Standard VGA output RGBHV, RGBS, RGsB, RsGsBs,
component video (bi-/tri-level sync)
Connectors 4 or 8 female RJ-45 output
1 HD15 local output
Nominal amplitude 1 V p-p for Y of component video
0.7 V p-p for RGB and for Pr and Pb of component video
4.0 V to 5.0 V p-p, for TTL Sync signals of RGBHV, RGBS
Impedance 75 ohms
Skew compensation 62 ns
Maximum resolution Up to 1920x1200 and 1080p at 750 ft; 1280x1024 at 850 ft
Polarity
Positive or negative
Audio
Gain
Unbalanced output: 0 dB
Frequency response 20 Hz to 20 kHz, ±1 dB
Connector
(1) 3.5 mm connector input
(1) 3.5 mm connector local output
Type Monaural, Simulated Stereo
THD + Noise 0.2% @ 1 kHz, 0.3% @ 20 kHz at nominal level
General
Recommended cable CAT 5/5e/6 (shielded or unshielded)
Power Supply
100 VAC to 240 VAC, 50-60 Hz, external; 6 VDC, 1.5 A, regulated; 2.1mm
Temperature/humidity Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, non-condensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, non-condensing
Enclosure type Metal
Dimensions 1.66" H x 8.42" W x 2.60" D - Depth excludes connectors
(42.2 mm H x 214 mm W x 66 mm D)
Product weight 1.5 lb (0.68 kg)
Shipping weight 3.0 lbs (1.36 kg)
Vibration ISTA 1A in carton (International Safe Transit Association)
Safety CE
EMI/EMC CE, FCC Class A
MTBF 90,000 hours
Warranty 2 years parts and labor
RS-232
Connectors 1 DB9 Female Input (Pins 2, 3 and 5)
1 DB9 Male Output (Pins 2, 3 and 5)
Specifications are subject to change without notice
