Model UV232A-4S and UV232A-8S
4
1.2 Features
• 4 channel (UV232A-4S) or 8 channel (UV232A-8S) splitter versions
• Transmits audio, video and uni-directional RS-232 on a single CATx cable
• Supports resolutions up to 1920x1200 at any refresh rate
• Compact & rugged metal enclosure with mounting holes
• Easily expandable by daisy-chaining receivers (URA-232-XT)
• Each URA-232-XT within the chain can send transmit RS232 or be
remotely triggered.
2. Installation
2.1 Package Contents
Your package should contain the following items:
(1) UV232A – 4S or UV232A-8S
(1) Universal power supply (6 VDC @ 1.5A) with IEC320 Power Cord
(1) 6 ft HD15-M-M VGA cable
(1) 6 ft 3.5mm – MM Audio cable
(1) User manual.
