UHBX-8X
17
7.0 Specifications
Video
Standards
DVI (single link) and HDMI (compliant with HDMI 1.4 video specifications
including 12 bit color depth, 3D video and 4K support)
Signal type TMDS
Connectors Locking HDMI
Resolutions DVI signal VGA (640x480) thru WUXGA (1920x1200)
HDTV signal 480i through 1080p
Digital Cinema 4K (4096x2160) – Not supported in Long Reach
Audio
Formats
All HDMI Embedded Audio including: LPCM 7.1CH, Dolby TrueHD and
DTS-HD Master Audio (32-192kHz sample rate)
Other Signals
DDC
Pass-Thru DDC for reading EDID directly from remotely connected LCD and
HDCP handshake. DDC clock must be less than 100 KHz and the source must
support clock stretching
CEC Pass-Thru CEC for Consumer Electronics Control compatible devices
RS232 Bidirectional (full-duplex) any baud rate up to 115,200
IR Extended in both directions. Carrier modulation range from 30 KHz to 60 KHz
PoH Power-over-HDBaseT meets IEEE 802.3af standard. The UHBX-3S supports
PoH power to devices that require power up to Class 2 (6.49 watts).
General
Power Supply 100 VAC to 240 VAC, 50-60 Hz, 1.5A, internal;
Power
30 watts (102 BTU/hr) maximum
Temp/humidity Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, non-condensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, non-condensing
Cooling Convection, with internal temperature controlled fan
Mounting 1RU high, standard 19" rack
Enclosure type Steel
Dimensions
1.75" H x 7.75" W x 19" L (44.45mm H x 196.85mm W x 482.6mm L)
Product weight Extender 6.9 lb or 3.13 kg
Shipping 8 lb or 3.6 kg includes: Extender, power cord, and manual
Vibration ISTA 1A in carton (International Safe Transit Association)
Safety CE
EMI/EMC CE, FCC Class A
MTBF 90,000 hours (Calculated Estimate)
Warranty 2 years parts and labor
Specifications are subject to change without notice
