Hall Research HR-731-S - Manual (Page 11)

HDMI and Serial over Single Fiber
9
7.0 Troubleshooting
Make sure that all of the connections to the units are solid, and check the state of
the LED’s on the front of the unit. Do not open or try to repair the unit yourself.
There is no customer repairable item in the unit and you will void your warranty.
Contact HR Support at 714-641-6607 or via email or web. If you need to ship
your unit for repair, make sure to get a Return Material Authorization (RMA)
number first.
8.0 Specifications
Video Inputs 1x HDMI or DVI
Supported
Resolutions HDTV from 480i to 1080p at any color depth, 4K30 8-bit
PC from VGA to WUXGA, 2560x1600@60 8bit color
Optical
Wavelength 780 nm to 980 nm
Optical
Cable Simplex (only 1 fiber) Multi-Mode. OM2 or OM3
Temperature Operating: 32 to 122°F (0 to 50°C);
Storage: –40 to +185°F (–40 to +85°C)
Enclosure Steel & Aluminum
MTBF 90,000 hours (calculated estimate)
Power 5V DC, 2.6A
Size (each) 1.25’’H x 2.75”W x 4.28”D (3.2x7.0x10.9 cm)
Weight (each) 0.4 pounds (0.18 kg)
