GoDEX EZ1105 series - Manual (Page 6)

EZ1105 / EZ1305 User Manual
2
Barcodes
1-D Bar codes:
Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-Mart,
UCC/EAN-128, UPC A / E (add on 2 & 5), I 2 of 5, I 2 of 5 with Shipping
Bearer Bars, EAN 8 / 13 (add on 2 & 5), Codabar, Post NET, EAN 128, DUN
14, HIBC, MSI (1 Mod 10), Random Weight, Telepen, FIM, China Postal
Code, RPS 128 and GS1 DataBar
2-D Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code and Micro QR code
Code Pages
CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869,
737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255
Unicode (UTF8, UTF16)
Graphics
Resident graphic file types are BMP and PCX, other graphic formats are
downloadable from the software
Interfaces USB port (default on)
Control Panel One Tri-color LED: Power (Green, Orange and Red)
Control key: FEED
Power Auto Switching 100-240VAC, 50-60Hz
Environment
Operation temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: -4°F to 122°F (-20°C to 50°C)
Humidity
Operation: 30-85%, non-condensing.
Storage: 10-90%, non-condensing.
Agency
Approvals
CE(EMC), FCC Class A, CB, CCC
Dimension
Length: 10” (254 mm)
Height: 6.7” (170 mm)
Width: 8.8” (224 mm)
Weight 5.5 lbs (2.5Kg) ,excluding consumables
Options
Internal RS-232 card
Ethernet 10/100Mbps print server (default off; disables USB when in use)
External label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder
*Specifications are subject to change without notice. All company and/or product names
are
trademarks and/or registered trademarks of their respective owners.
** Minimum print height specification compliance can be dependent on non-standard
material
variables such as label type, thickness, spacing, liner construction, etc. Godex is pleased to
test
non-standard materials for minimum height printing capability.
