11

gp

electric.com

GP-RV-80

GP-RV-95

GP-RV-160

GP-RV-80E

GP-RV-95E

GP-RV-160E

Weekender SW

Weekender HD

Solar Elite

Solar Extreme

Diagram 2

Negative MC4 Parallel Connector - Female

Wiring Parallel (2) Modules with MC4 Parallel Connectors

Positive MC4 Parallel Connector - Male

Note: solar module junction box and MC4 cables many not

be exactly as shown.

MC4 Extension Cable to Solar Controller or Combiner Box

MC4 Cable Connections for 2 Parallel Modules

E.G. Two 12V modules at 12V

MC4 Parallel - Male

MC4 Parallel - Female
