INSTALLATION
EN
12.2.2 Menus and functions
The available settings are diff erent depending on the installation
layout and the options selected.
Menus and functions
Installation
Modifying the installation (*)
This menu allows you to change the diagram number when modifying
the installation’s confi guration.
A diagram number is assigned to each possible installation, with
various options available. The number is indicated in the system
manual.
Modifi cation options (*)
This menu allows you to enable or disable the options available in the
selected installation diagram.
Thermostat/sensor (wireless)
Thermostat connection(s)
Sensor connection
Ext. temperature correction
Automatic test
EBUS inputs
NTC inputs
the RF connection with the Climapro2 room thermostat
the outdoor sensor radio connection
I/O card
Parameters
Heating
Max. heating outlet T°
Auto heating curve
Manual heating curve
Advance heating
Hot water
Max. domestic hot water temperature
Cooling
Cold water outlet temperature setting
Energy management
Resetting parameters
The resetting of factory settings is irreversible. Any customised
confi guration of the control unit will be lost.
Commissioning
This menu allows you to carry out the necessary operations on
the appliances following installation (refi lling, bleeding, fl ow rate
control...).
Component information (**)
This menu enables real-time access to:
- the status of the appliances responding to a demand (ON / OFF)
- the reading the diff erent information available from the appliances
(temperature, pressure, fl ow,)
- the register of last 5 faults recorded for each appliance (date, time,
code and description of faults).
- resetting the fault report.
Options
Date (***)
Time (***)
Automatic winter/summer time change
Languages
Screen (brightness / contrast)
About
This function is used to display the versions of the various electronic
components attached to the management box.
i
(*) On entry into the menus installation modifi cation
and options modifi cation, the management box warns
that “the system is shutting down”. “the system is
currently stopped" No further heating control operations
are eff ected. ... Setting will restart after leaving these
menus.(**) Refer to the system manual to fi nd the
description of the fault code displayed on the screen.
(***) The date and time are set from the room thermostat
in an individual installation.
13 Specifi c adjustment
13.1 Wireless connections
13.1.1 Pairing with the wireless thermostat(s)
This function lets you perform the pairing between the Climapro2
RF and the radio receiver.
In the case of an individual installation which includes a low
and high temperature heating zone. “Zone 1” must imperatively
be allocated to a low temperature heating zone. The room
thermostat in zone 1 has the “main thermostat” status.
Adjustments must be made simultaneously to the control unit and
the room thermostat.
Via the control unit:
• From the installation menu in the control unit > select on the
screen > thermostat/sensor > room stat(s)
Via the room thermostat:
• Via the installer room thermostat menu > select on the screen >
RF > pairing
The control unit and the room thermostat will immediately
indicate recognition on their respective "connection in progress"
screens.
13.1.2 Pairing with wireless outdoor sensor
• Consult the outdoor sensor’s installation manual in order to
carry out the operation.
