TECHNICAL DATA
- 7 -
14732
BOILER SPECIFICATION
24cx 30cx 35cx
Lift weight
36kg (79Ib)
36kg (79Ib)
36kg (79lb)
Total weight (installed)
41kg (90Ib)
41kg (90Ib)
41kg (90lb)
Gas connection Ø O.D. 15mm. copper
15mm. copper
15mm. copper
Heating and return connection Ø O.D.
22mm. copper
22mm. copper
22mm. copper
Domestic hot water connection Ø O.D.
15mm. copper
15mm. copper
15mm. copper
Condensate connection Ø I.D.
21.5mm. plastic
21.5mm. plastic
21.5mm. plastic
Safety valve discharge connection ØO.D. 15mm. copper
15mm. copper
15mm. copper
Heating circuit safety valve (preset)
3 bar (43.5Ibf/in
2
)
3 bar (43.5Ibf/in
2
)
3 bar (43.5Ibf/in
2
)
Heating system minimum pressure
0.7bar (10.1Ibf/in
2
)
0.7bar (10.1Ibf/in
2
)
0.7bar (10.1Ibf/in
2
)
Maximum domestic hot water circuit
10bar (145Ibf/in
2
)
10bar (145Ibf/in
2
)
10bar (145Ibf/in
2
)
1.0bar (14.5lbf/in
2
)
1.0bar (14.5lbf/in
2
)
1.0bar (14.5lbf/in
2
)
0.2bar (2.9Ibf/in
2
)
0.2bar (2.9Ibf/in
2
)
0.2bar (2.9Ibf/in
2
)
Specific water rate at 35° rise
9.85L/min.
12.3L/min.
14.4L/min
Min. flow rate around C.H. at 20° rise
776L/hr. 1032L/hr.
1204L/hr
Maximum domestic hot water temperature 63°
63°
63°
Expansion vessel capacity
8 litres (1.76 gallons)
8 litres (1.76 gallons)
8 litres (1.76 gallons)
Expansion vessel charge pressure
0.5bar (7.3Ibf/in
2
)
0.5bar (7.3Ibf/in
2
)
0.5bar (7.3Ibf/in
2
)
Electrical supply 230V~50Hz fused 3A
230V~50Hz fused 3A
230V~50Hz fused 3A
Electrical rating 180W fused 3A
180W fused 3A
180W fused 3A
EN437 IP clasification
IPX4D IPX4D IPX4D
Internal fuse rating on main PCB
2A
2A
2A
Gas supply (governed meter only) and Cat G20 natural gas G20 natural gas G20 natural gas
Gas Category
I
2H
I
2H
I
2H
Inlet gas working pressure 20mbar 20mbar 20mbar
Burner % CO
2
case on
9.3 nominal
9.3 nominal
9.3 nominal
Burner % CO
2
case off
9.3 nominal
9.3 nominal
9.3 nominal
1.93 m
3
/h
2.59 m
3
/h
3.26 m
3
/h
68.1 ft
3
/h
91.5 ft
3
/h
115 ft
3
/h
0.99 m
3
/h
0.99 m
3
/h
0.99 m
3
/h
35.1 ft
3
/h
35.1 ft
3
/h
35.1 ft
3
/h
Flue type
C
13
, C
33
, C
43
C
13
, C
33
, C
43
C
13
, C
33
, C
43
NOx
Class 5 Class 5 Class 5
Heat output condensing mode
18.8kW 24.9kW 31.0kW
Heat input Nett Q = kW DHW max. 25.5 min. 9.4 DHW max. 30.8 min. 9.4 DHW max. 35.8 min. 9.4
CH max. 18.3 min. 9.4
CH max. 24.5 min. 9.4
CH max. 30.8 min. 9.4
Heat output P = kW
DHW max. 25.1 min. 9.3 DHW max. 30.0 min. 9.3 DHW max. 35.0 min. 9.3
CH max. 18.0 min. 9.3
CH max. 24.0 min. 9.3
CH max. 30.0 min. 9.3
SEDBUK rating %
2005
90.3
90.0
90.2
SEDBUK rating %
2009
88.4
88.3
89.1
Approximate max. gas rate
after 10 mins. from cold
Approximate min. gas rate
after 10 mins. from cold
Minimum working pressure to obtain
domestic hot water
Minimum working pressure to obtain
maximum domestic flow
PLEASE REFER TO THE COMMISSIONING SECTION
Approximate gas rate
at part load.
1 Boiler Specification
