Appendix
34
Installation instructions Envirosorb₃ 0020154078_03
Technical data – Coolant circuit
Envirosorb
3
5
Envirosorb
3
8
Envirosorb
3
11-1 ph
Envirosorb
3
15-1 ph
Coolant type
R410A
R410A
R410A
R410A
Coolant contents
1.80 kg
1.95 kg
3.53 kg
4.40 kg
Maximum permissible
operating overpressure
4.15 MPa
(41.50 bar)
4.15 MPa
(41.50 bar)
4.15 MPa
(41.50 bar)
4.15 MPa
(41.50 bar)
Compressor type
Rotary piston
Rotary piston
Rotary piston
Rotary piston
Oil type
Specific
polyvinyl ether
(PVE)
Specific
polyvinyl ether
(PVE)
Specific
polyvinyl ether
(PVE)
Specific
polyvinyl ether
(PVE)
Coolant circuit control
system
Electronic
Electronic
Electronic
Electronic
Technical data – Heat pump system performance data
Envirosorb
3
5
Envirosorb
3
8
Envirosorb
3
11-1 ph
Envirosorb
3
15-1 ph
Heating output A-7/W35
4.90 kW
6.20 kW
7.60 kW
11.80 kW
A-7/W35 output figure/EN
14511 coefficient of per-
formance
2.40
2.40
2.40
2.60
A7/W35 heating output
4.70 kW
7.60 kW
10.60 kW
14.60 kW
A7/W35 output figure/EN
14511 coefficient of per-
formance
4.70
4.50
4.30
4.50
Power consumption ef-
fective at A7/W35
1.10 kW
1.69 kW
2.47 kW
3.40 kW
Input current at A7/W35
4.80 A
8.28 A
12.04 A
14.80 A
A7/W45 heating output
4.40 kW
7.20 kW
10.20 kW
13.40 kW
A7/W45 output figure/EN
14511 coefficient of per-
formance
3.40
3.50
3.35
3.40
Power consumption ef-
fective at A7/W45
1.30 kW
2.06 kW
3.05 kW
4.10 kW
Input current at A7/W45
5.70 A
9.61 A
14.13 A
17.80 A
A7/W55 heating output
4.20 kW
6.60 kW
9.40 kW
11.20 kW
A7/W55 output figure/EN
14511 coefficient of per-
formance
2.70
2.70
2.60
2.30
Power consumption ef-
fective at A7/W55
1.60 kW
2.44 kW
3.61 kW
5.00 kW
Input current at A7/W55
7.00 A
10.86 A
16.49 A
21.70 A
D
Status codes
Code Meaning
0
Product in standby mode
1
Heating mode: Pump pre-run
2
Pump pre-run OK
3
Water temperature/setting compatibility test
4
Heating mode start phase activated
5
Heating mode: Pump pre-run to max. speed
6
Heating mode: Fan pre-run
7
Heating mode: Move 4-way valve into position
8
Heating mode: Move electronic expansion valve into
position
