Appendix
0020154078_03 Envirosorb₃ Installation instructions
33
Envirosorb
3
5
Envirosorb
3
8
Envirosorb
3
11-1 ph
Envirosorb
3
15-1 ph
Electric connection
230 V/50 Hz
230 V/50 Hz
230 V/50 Hz
230 V/50 Hz
Fuse type
T4A
T4A
T4A
T4A
Inverter controller fuse
HRC 20 A 550
V
HRC 20 A 550
V
HRC 32 A 550
V
HRC 32 A 550
V
Level of protection
IP 25
IP 25
IP 25
IP 25
Maximum start-up cur-
rent
16 A
16 A
20 A
25 A
Maximum current con-
sumption
16 A
16 A
20 A
25 A
Pump power consump-
tion
15 … 70 W
15 … 70 W
15 … 70 W
6 … 87 W
Fan power consumption
15 … 42 W
15 … 42 W
15 … 76 W
15 … 76 W
Note
2 x
Electrical classification
I
I
I
I
Overvoltage category
II
II
II
II
Fan rotational speed
550 rpm
550 rpm
675 rpm
600 rpm
Sound power level for
A7W35 according to EN
12102 and EN ISO 9614-1
58 dB(A)
60 dB(A)
65 dB(A)
65 dB(A)
Sound power level for
A7W45 according to EN
12102 and EN ISO 9614-1
59 dB(A)
60 dB(A)
65 dB(A)
65 dB(A)
Sound power level for
A7W55 according to EN
12102 and EN ISO 9614-1
61 dB(A)
61 dB(A)
66 dB(A)
66 dB(A)
Maximum cylinder tem-
perature
60 ℃
63 ℃
63 ℃
63 ℃
Minimum air temperature
(heating and cylinder
charging)
−15 ℃
−20 ℃
−20 ℃
−20 ℃
Maximum air temperature
(heating)
28 ℃
28 ℃
28 ℃
28 ℃
Maximum air temperature
(hot water generation)
46 ℃
46 ℃
46 ℃
46 ℃
Max. air flow
2,000 m³/h
2,700 m³/h
3,400 m³/h
5,500 m³/h
Technical data – Heating circuit
Envirosorb
3
5
Envirosorb
3
8
Envirosorb
3
11-1 ph
Envirosorb
3
15-1 ph
Minimum operating pres-
sure
0.1 MPa
(1.0 bar)
0.1 MPa
(1.0 bar)
0.1 MPa
(1.0 bar)
0.1 MPa
(1.0 bar)
Maximum operating pres-
sure
0.3 MPa
(3.0 bar)
0.3 MPa
(3.0 bar)
0.3 MPa
(3.0 bar)
0.3 MPa
(3.0 bar)
Heating circuit water con-
tents in the heat pump
1.1 l
1.6 l
2.1 l
2.7 l
Minimum heating circuit
water contents
17 l
21 l
35 l
60 l
Min. volume flow rate
380 l/h
380 l/h
540 l/h
1,200 l/h
Nominal volume flow
rate, max. volume flow
rate
860 l/h
1,400 l/h
1,900 l/h
2,590 l/h
Hydraulic pressure differ-
ence
640 mbar
450 mbar
300 mbar
370 mbar
Expansion vessel capa-
city
2.0 l
2.0 l
2.0 l
2.0 l
