Generalmusic GRP-800 - Manual (Page 16)

Page12
owner's manual rp800
Page13
owner's manual rp800
DATA
BALANCE
DATA
BALANCE
DATA
BALANCE
DATA
BALANCE
FUNCTIONS: Rp 800 functions menu
Functions Function Lev. 2 Function Lev. 3 parameter range parameter range
F1 Temperaments Equal, Piano 1, Piano 2, Meantone, Kirnberger, Tartini Vallotti
F2 Global tune - - from 427 to 452 Hz.
F3 Midi In from 1 to 16, common - from 1 to 16 ,off
F4 Midi Out from 1 to 16, common - from 1 to 16 ,off
F5 Midi Local On/Off
F6 Midi In Transpose - - On/Off
F7 Midi Out Filters - - Off(0)/PrgChg(1)/CtrChg(2)/Both(3)
F8 StartUp Mode -. - Factory/User
F9 Midi Dump - - Press data button to start MIDI dump
F10 PC mode - - PC1, PC2, Mac
F11 Reverb (1) Tipo rev Depth, Time, Predelay
F12 Efx (1) Tipo efx Depth, Par. 1, Par. 2
F13 Equalizer Equalizer On/Off
F14 Damper phys. Mod. On/Off
The Rp 800 functions menu allows to fine adjust the instrument to different operating situations.
F2- Global Tune
This function allows to fine adjust the Rp 800's pitch.
+ -
Press the
Functions button Pressing the DATA button the display shows the current
tune value (standard pitch A=440 by default).
Edit the value using
BALANCE DATA buttons,
from 427 to 452 Hz.
F1- Temperaments
This function allows to select the various temperaments featured by the Rp 800.
Press Functions
button
Select F1 using SELECT/TEMPO buttons
Pressing the DATA button the display shows the
current temperament value (Equal by default). Edit the value using
the DATA buttons.
01 Equal Equal
02 Piano 1
03 Piano 2
04 Meantone
05 Kirnberger Kirnberger
06 Tartini Vallotti
F3- MIDI in
This function allows to edit the Rp 800 MIDI In configuration.
Press the
Functions button
Select F3 using
the SELECT/
TEMPO buttons
The Functions
button starts
blinking
Press the
button again
Select a section using
the SELECT TEMPO
buttons
MAIN
LAYER
SPLIT
COMMON
Edit MIDI channel
number using the DATA
buttons
VALUE: From 1 - 16 to OFF
DISPLAY
Select F2 using SELECT/TEMPO buttons
