- 5 -
DIP Switch Function:
Switch
number
1 2 3 4
ON
For
Factory
use only
Flight
Mode
Selection
Flight
Mode
Selection
Not
used
OFF
Always
OFF
position
Flight
Mode
Selection
Flight
Mode
Selection
Not
used
Blue LED
Blue LED Continuous flashing On Solid
Flight Mode Status Auto Stabilization 3D Mode
Red LED
Red LED OFF Aircraft is stationary but
Red LED Flashes
ON Solid
Status Indicator Normal Need to initialize the gyro/
moving
High Vibration Detected. Does not
meet system requirement.
Gyroscope initialization (re-setting):
Out of the box, the FY-30A has been fully initialized. However, if the following condition
occurs, resetting the gyro is recommended:
1. The device is kept unused for a long time.
2. There is a change in environmental temperature of over 30 degrees.
3. The red LED light flashes even when the aircraft is stationary.
Initialization / Reset Procedure
Install the jumper as shown in this picture:
Power-ON the FY-30A and keep it stationary for at
least 20 seconds. You will notice the red light blinks at
two different rates (or turns off). Re-setting of Gyro is
completed. Disconnect power, unplug the jumper and keep it in a safe place for future
use).
NOTE:

Carry out this re-setting procedure only if the condition (above) occurs. It is not
recommended to regularly reset the gyro. It is not necessary.

The stabilizer unit does not need to be in a horizontal position during initialization.
However, you must ensure there is no vibration during this process. If you suspect
B
A
8
C
7 6 5 4 3 2 1
1 2 3 4
OFF
ON
