Auto Take Off
1. The auto take-off feature is designed mainly for hand launched planes.
2. Please select a fairly stable plane if auto take-off is to be used.
3. The Auto Take-off should not be attempted unless you have completed setting up Auto
Balance mode and fill in the Navigation
parameters.
4. Critical Parameter Examples:

Set the climb pitching angle for auto
take-off.

Set the climbing Groundspeed for auto
take-off

Mission: Circle over home-point after
auto take-off.
Auto take off procedure
1. After located by the GPS, click ―Auto Launch‖ in the GCS.
2. When the menu button background color turn to green, set Channel 6 switch to the
position of ―Return to home‖
3. Set the throttle level to the position for taking off.
4. Throw out the plane in a level and straight way.
5. You will notice the plane will fly in a straight line first.
6. When the autopilot detects groundspeed has increased at a value needed for climbing, the
plane will climb up to approximately 50m altitude.
7. Upon reaching 50 meter altitude, the auto take off Procedure is over. Control is
automatically transferred back to your RC transmitter.
8. However, the plane will still continue flying autonomously, gradually circling and
increasing height to 100 meters over the home-point. At this height, the aircraft will hold
altitude.
9. Remember that if you had done any adjustments to the Flight Parameters (e.g. Pitch and
Roll stability), remember to click ―Save to AP‖ to store your settings in the Autopilot.
Failure to save these settings before powering off will result in lost of all adjustments
done.
This manual is just a guideline to help you set up your aircraft for autonomous flight.
As each aircraft is unique, you will need to fine tune the settings to suit your aircraft’s
flight characteristics.
