OPTION 3: GROUND STATION CONTROL DIAGRAMME
WARNING: If you wish to use a 5 volt
Receiver battery to power the ground
station system, please disconnect the 5
volt power in-coming from the USB
Interface cable.
USB—Serial TTL
RC Remote Receiver
AIL
THR
CH5
ELE
CH6
RUD
Data radio
Receiver battery
