EXFO MaxTester MAX-610 User Manual
Page 94
Reading Saved Copper Test Results
86
MAX-610
Read Result Menu
Function keys:
Save keeps any current changes with the current file name.
Save As saves the current changes under a different file name that
you can configure in the editor screen.
Don’t Save does not save any changes and closes the page.
Report allows you to load a result file to a USB device, update the
ID fields, and generate a report in either HTML, MHTML, or XML
format.
Upload (in User Auto Test only) allows you to transfer an Auto
Test result file to an FTP site or USB device via the presently
selected method (Wi-Fi or Ethernet).
To view and edit the test result information:
1. Press the up/down arrow keys to highlight and view the desired
parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
on an editable value to open the list box of options or the
alphanumeric editor screen. Use the navigation keys to scroll through
and select.
4. Press
to confirm the value.
