Introducing the FTB-9100 Optical Switch
Optical Switch
3
Typical Application, OTDR Testing
Typical Application, OTDR Testing
You can use your switch to test several fibers with an OTDR without having
to connect and disconnect them before each acquisition.
For more information, refer to the EXFO OTDR user guide.
FTB-9100
OPTICAL SWITCH
1
5
6
2
3
7
4
8
9
10
11
12
COMMON
SM OTDR
Patchcord
Fibers
under test
