Optical Switch
15
3
Operating the Optical Switch
Before using the FTB-9100 Optical Switch in a test setup, you must first
connect the ports to other test components and select a switching
configuration.
Note: You can configure your switch before connecting it to your test setup.
C
AUTION
Your Optical Switch contains sensitive precision optical
components. To ensure reliable, long-term service, observe proper
handling and operating instructions. At no time should the module
be subject to shock or impact.
