Table 1: electrochemical sensors – ENMET EN Series User Manual
Page 7
Sensor/Transmitter, Toxic Gas & Oxygen
ENMET Corporation
5
4.0
Standard Ranges, Calibration Gases, Voltage Readings at Calibration Points and
Approximate Times to Sensor Stabilization
Table 1: Electrochemical Sensors
Gas
Symbol
Range*
(ppm)
Calibration Gas
Correlation
Reading
(mV)
Stabilize
(min.)
ENMET Gas
Part Number
Ammonia
NH
3
0 – 100
25ppm NH
3
200
4
03218-025
Arsine (2)
AsH
3
0 – 0.5
0.5ppm PH
3
0.375ppmAsH
3
400
3
03202-005
Boron Trichloride
BCl
3
0 – 30
10ppm HCl
10ppm BCl
3
233
3
03202-010
Carbon Monoxide
CO
0 – 100
50ppm CO
300
2
03219-050
Chlorine (2)
Cl
2
0 – 10
5ppm Cl
2
300
4
03231-005
Chlorine Dioxide
ClO
2
0 – 1.0
0.3ppm ClO
2
**
220
4
**
Dichlorosilane
SiH
2
Cl
2
0 – 30
10ppm HCl
3ppm SiH
2
Cl
2
140
3
03202-010
Ethylene Oxide
C
2
H
4
O
0 – 30
5ppm C
2
H
4
O
167
3
03232-005
Fluorine (2)
F
2
0 – 10
3ppm Cl
2
7.5ppm F
2
400
3
03231-003
Hydrogen
H
2
0 – 1000
800ppm H
2
420
3
03227-800
Hydrogen Bromide
HBr
0 – 30
5ppm HCl
25ppm HBr
433
3
03202-005
Hydrogen Chloride (2) HCl
0 – 30
10ppm HCl
233
3
03202-010
Hydrogen Cyanide
HCN
0 – 30
10ppm HCN
233
2
03203-010
Hydrogen Fluoride (1)
HF
0 – 10
5ppm Cl
2
3ppm HF
220
4
03202-005
Hydrogen Sulfide
H
2
S
0 – 100
20ppm H
2
S
180
2
03214-020
Nitrogen Dioxide
NO
2
0 – 30
5ppm NO
2
167
2
03233-005
Nitric Oxide
NO
0 – 100
25ppm NO
200
1.5
03234-025
Oxygen
O
2
0 – 30 %
20.9% O
2
379
2
03296-209
Ozone (1)
O
3
0 – 1.0
0.3ppm O
3
**
220
3
**
Phosgene (1)
COCl
2
0 – 1.0
0.66ppm COCl
2
**
364
4
**
Phosphine (2)
PH
3
0 – 1.0
0.5ppm PH
3
300
1.5
03205-005
Silane
SiH
4
0 – 30
5 ppm SiH
4
167
2
03306-005
Silicon Tetrachloride
SiCl
4
0 – 30
5ppm HCl
25ppm SiCl
4
433
3
03202-005
Sulfur Dioxide
SO
2
0 – 30
10ppm SO
2
233
1.5
03215-010
N
OTE
:
All specifications stated in this manual may change without notice.
(1) Require use of Sample Draw System.
(2) Recommended use of Sample Draw System, for enhanced sensitivity and speed of response.
*0 = 4mA = 100mV, upper point = 20mA = 500 mV
**Gas not available in cylinders, a gas generator must be used
N
OTE
: If a non-standard range and/or a non-standard calibration gas are used, utilize the equations in Section 3.0 to determine
voltage readings.
