Page 6

ENMET Corporation
MX48 C
ONTROL
2
2.0 Features
2.0 Features
2.0 Features
2.0 Features
2.1 The wall-mounted enclosure
The enclosure of the
MX48 C
ONTROL
is a wall-mounted box consisting of a case and a cover that can be
pivoted up to access the interior.
For overall dimensions see section 3 installation, Figure 2 exterior view.
For over view of interior see Figure 1 interior view.
Figure 1: Interior View of MX48 C
ONTROL
Figure 1a: On/Off Switch Power Supply Board
¼ turn latches, 2 pl
Power Supply Board
See Figure 1a
Locking Brace
to hold cover open
Transformer
Display Board
Keypad
Channel 1 – 4 Board
Channel 5 – 8 Board
Cable Glands, 15 pl
Enclosure
Power On/Off
Switch
