ENMET MX-48 User Manual

Page 18

ENMET Corporation

MX48 C

ONTROL

5.3.2 Legend for Block Diagrams of Programming Menus

It is easy to use these various menus by means of the switches on the keypad and the “Programming” switch

Detailed flow diagrams of the menu scrolling function and of each menu are given in the following sections.

Programming switch

Switch used to move forward

Switch used to move in reverse

E N T E R

Switch used to enter data

This switch can also be used to exit from the current menu.

When in a menu, you can go back (to make checks or modifications, etc...) by

pressing and holding down switch

and by successively pressing and releasing the

Programming switch.

[ ]

Parameters specified in square brackets [ ] are the VALID parameters (in memory).

(1) Free

This means that the relay can be controlled freely in positive or normal safety mode
(programming by

MX48

Set to



Set to 1

This means that the relay will be controlled, set to 0 or 1, and programmed directly via
the J.BUS input and the “

COM

” software.

ACQUIT
