1.0 Description
The QUADRANT is a portable multi-gas detector. It can simultaneously detect the
presence of up to four gases by means of special sensors for each type of gas to be
detected. Included are explosive gases such as methane, propane, butane, etc., two toxic
gases, carbon monoxide and hydrogen sulfide, and the oxygen content of the air.
1.1 Upon Receipt
1.1.1 Unpack
Unpack instrument and examine it for shipping damage. If such damage is observed,
notify both ENMET customer service personnel and the commercial carrier involved
immediately; save the shipping box and packing material.
1.1.2 Items Included
The following items are included in a shipment:
• the instrument, with battery and two, three or four sensors, as ordered
• the charger base
• the power supply
• the calibration shield
• the manual
1.1.3 Sensor installations are as follows:
Instrument Part Numbers
Model Sensors
02600-000 Q-4 Comb,O2,CO,H2S
02600-001 Q-3C Comb,O2,CO
02600-002 Q-3H Comb,O2,H2S
02600-003 Q-2 Comb,O2
1.1.4 Check Sensors
Look into the sensor ports on the cover of the instrument, to determine the number and
type of toxic sensors that are installed.
1.1.5 Check Instrument
The instrument is supplied with a wall plug power supply and a charging base. To
charge the instrument, plug the power supply into the wall and its other connector into
the back of the charging base. Insert the instrument into the base (note instrument
contour and base contour). During the charging process, the alarm LEDs flash
sequentially and a pattern is displayed on the LCD. The instrument is fully charged after
about 4 hours. When the instrument is removed from the charger it performs an auto-
zero which sets gas readings to 0 and oxygen to 20.9%; this must be done in clean air.
2.0 Features
The features of the QUADRANT are shown in Figure 1 on page 1. These are:
