5
To increase the current (amperage), connect the cells in parallel. (Positive point connect to
positive point, negative point connect to negative point). The more cells you use, the more
power you get.
Figure 13 Figure 14 Figure 15
I
1
1.5V 100mA connecting
system (see Figure 13).
I
2
1.5V 200mA connecting in
parallel system (see Figure 14).
I
3
1.5V 300mA connecting in parallel
system (see Figure 15).
I
1
I
2
I
3
Figure 16 Figure 17 Figure 18
Screw point No.1 and No.2 are the
output (see Figure 11 & 30). Positve screw point (No.2)
connect to positive (No.4),
negative (No.1) connect to
negative (No.3), then No.1 and
No.4 are the output at 1.5V
200mA (see Figure 17, 20 &
21). Positve screw point (No.2)
connect to positive (No.4),
negative (No.1) connect to
negative (No.3), positve (No.4)
connect to positive (No.6),
negative (No.3) connect to
negative (No.5), then No.1 and
No.6 are the output at 1.5V
300mA or No.1 and No.2 are the
same output at 1.5V 300mA (see
Figure 18, 20, 21, 22, 23 & 24).
1.5V
100MA
To increase the current (amperage I), formula as follows:
I total = I
1
+ I
2
+ I
3
e.g.:(I
1
)100mA + (I
2
)100mA + (I
3
)100mA = 300mA
E total = E
1
= E
2
= E
3
But the voltage (V) remains constant at 1.5V
1.5V
100MA
1.5V
300MA
1 2 3 4 5 6
1.5V
100MA
1 2 3 4 5 6
1.5V
200MA
1 2 3 4 5 6
1.5V
300MA
