Elenco Deluxe Solar Educational Kit - Manual (Page 14)

14
Use 1.5V 300mA connected panel to power a motor
fan
Figure 42
Slide the angle stand into the base part
Figure 41
4.5V 100mA connecting system is recommended for
using musical unit, battery charger, game appliances,
etc.... Place the solar panel to face sunlight directly
for the best performance
Figure 44
Slide the angle stand into the slot of the panel, or it
can be released by pull up the ‘Against Locker’ and
slide it off
Figure 43
Tighten a little bit with screw driver for standing itself
if necessary
Figure 45
