QUIZ
1. The Space War Gun has two ____________ _____________ oscillators.
2. Capacitor C3 and resistors R3 and R4 controls the _____________ of oscillation.
3. The charge time of capacitor C3 is through resistors ______ and ______.
4. The discharge of capacitor C3 is through resistor ______ and the ______.
5. The 555B timer operates at a __________ frequency than the 555A timer.
6. Increasing the value of capacitor C2 will ___________ the frequency of oscillation.
7. Increasing the voltage of VCO pin 3 of the 555B timer will __________ the frequency of oscillation.
8. VCO stands for ____________ ____________ _____________.
9. In the Space War Gun design, the 555A timer controls the frequency of the _____________ timer.
10. Resistor R6 is added to ___________ the current in the LEDs.
Answ ers: 1. astab le multivibr ator; 2. frequency; 3. R3, R4; 4. R4, IC; 5. higher; 6. low er; 7. decreases; 8. v oltage controlled oscillator ; 9. 555B; 10. limit
