East Coast Supercharging ECS Alky 5th Gen User Manual
Page 5
3) Tank assembly
The factory washer reservoir will be used for the methanol. You will need to
unmounts it from car to drill the holes for the outlet and the low level float. The
drill size for these fittings is 7/8. TIP.. use a Unibit that max size is 7/8. To locate
the placement, simply hang the pump on the horn bolt and install by the hand
the 5.5 inch feed hose. Now this will let you know where to mark the hole for the
outlet fitting.
The low level will mount on the side of the tank below the frame rail. It will also
require a 7/8 hole to be drilled. Its electrical connections will face the ground.
Drill hole 1 inch from bottom to allow float to pivot.
Simply insert rubber grommet into hole, lube with WD 40 and push fitting in.
This applies to both the low level and outlet fittings.
Remember to wash out tank of any debris. Install plug into factory hole. And
install cap with breather.
