TO OPERATE: Be sure that the gold-colored powder pan is set on top
of the silver-colored pan support before zeroing the scale.
The scale has three poises: 0 - 500 grains in 10 grain increments; 0 -
10 grains in 1 grain increments; 0 - 1 grain in .1 grain increments. Be
sure that the poises are all set at zero before leveling the beam with the
white plastic leveler foot.
Make sure that the end loop on the balance beam has not been bent or
twisted. This is the loop that the powder pan hangs from. The loop must
move freely.
Inspect the copper damper vane to make sure it is not bent. It should
be centered in the notch.
Do not use any lubricant on any part of the scale. Keep all surfaces
clean and free of corrosion.
Dillon Eliminator Scale
Eliminator Scale, #13480
Poises
Copper Damper Vane
End
Loop
Leveler Foot
