M2 User Manual
5
M2 Key Features
SEPARATE AM AND FM ANTENNA INPUTS – Industry standard 75-ohm “F” connectors
AM AND FM HIGH LEVEL INPUTS – Industry standard 50-ohm “BNC” connectors; 7vP-P maximum
ANTENNA - HIGH LEVEL INPUT SELECT – User selected for antenna or high-level inputs
STEREO ANALOG OUTPUTS – Balanced (+4dBm) for 100% analog modulation
DIGITAL AUDIO OUTPUT – 110-ohm transformer isolated for HD Radio
TM
broadcast audio IEC320
POWER INLET – Integrated fuse holder on rear panel
SYNTHESIZED, PUSHBUTTON TUNING – AM and FM bands including multicast channels
PRESETS – 20 preset stations for each AM and FM band
DEMODULATED AUDIO LEVEL METERS – Displays Left and Right or L+R and L–R demodulated
audio between +10dB and –64dB Factory preset to display de-emphasized program audio
CARRIER LEVEL METER – Displays positive or negative peaks, or both simultaneously from 46% to
125% with a user programmable measurement integration time Factory preset for 100uSec
HD LOCKED – HD Radio TM audio present, indicates digital carrier SN > 58dB/Hz
DELAY BIT – Indicates active analog diversity delay for HD Radio TM broadcasts
A-D SPLIT MODE – HD Radio TM level, phase and time alignment monitor for analog diversity delay
HEADPHONE OUTPUT – Screwdriver gain control on front panel
PROGRAMMABLE STATUS ALARMS – M2.2R provides 6 dry-contact relays
M2 Technical Specifications
RF TUNING RANGE AM – 520kHz to 1720kHz in 10kHz increments
FM – 87.9MHz to 108.1MHz in 200kHz increments
RF USEABLE SENSITIVITY AM – 5dBf for SNR –20dB referenced to 30% modulation
FM – 5dBf for SNR –30dB referenced to 100% modulation
IF REJECTION AM – greater than 100dB for SNR –20dB
FM – greater than 100dB for SNR –30dB
AF BANDWIDTH AM – + 1dB 40Hz to 15kHz
FM – + 1dB 20Hz to 20kHz
AF THD+N < 0.005% (digital audio)
STEREO CHANNEL SEPARATION > 90dB (digital audio)
HD Radio
TM HYBRID ACQUISITION < 4.5 seconds
HD Radio
TM BLEND LEVEL ACCURACY < 0.5dB
HD Radio
TM
PAD DATA DISPLAY HD Radio
TM
data fields limited to a total of 1018 bytes per
message per iBiquity
TM
specifications.
