16
M2 User Manual
Push “SELECT” to continue.
A U D I O L O S S
>
S E T < O F F
• If “SET” is selected, submenu for “Level” threshold with “LOW”, “MED” and “HIGH”
options is displayed next. “LOW” option sets audio loss threshold for approximately
-60dB; “MED” option sets audio loss threshold for approximately -40dB; and “HIGH”
option sets audio loss threshold for approximately -20dB. Use UP and DN switches
to toggle the setting and highlight the desired option. Push “SELECT” switch to
continue.
A U D I O L E V E L
L O W > M E D < H I G H
• Submenu for “Alarm Delay” with “30”, “60”, “120” and “240” second options is
displayed next. Use UP and DN switches to toggle the setting and highlight the
desired option.
A L A R M D E L A Y
3 0 > 6 0 < 1 2 0 2 4 0 S
Push “SELECT” switch to save and increment the menu to the next alarm function.
Alarm Output 3 – OFDM Lock Loss (HD Radio
TM
modem lock)
• Highlight desired “SET” or “OFF” option using UP and DN switches to toggle the
setting. Select “SET” to set this monitor alarm and continue with alarm configuration
menu; select “OFF” to set this monitor alarm function to off. Push “SELECT” to
continue.
O F D M L O C K L O S S
>
S E T < O F F
• If “SET” is selected, submenu for “Alarm Delay” with “30”, “60”, “120” and “240”
second options is displayed next. Use UP and DN switches to toggle the setting and
highlight the desired option.
A L A R M D E L A Y
3 0 > 6 0 < 1 2 0 2 4 0 S
