M2 User Manual
17
Push “SELECT” switch to save and increment the menu to the next alarm function.
Alarm Output 4 – RBDS Data Loss (alarm based on data appearing in Radio Text field; available
in M2.2R model only)
Alarm Output 5 – HD Radio TM PAD Loss (alarm based on data appearing song title field only,
does not mean data is valid)
• Highlight desired “SET” or “OFF” option using UP and DN switches to toggle the
setting. Select “SET” to set this monitor alarm and continue with alarm configuration
menu; select “OFF” to set this monitor alarm function to off. Push “SELECT” to
continue.
P A D D A T A L O S S
>
S E T < O F F
• If “SET” is selected, submenu for “Alarm Delay” with “30”, “60”, “120” and “240”
second options is displayed next. Use UP and DN switches to toggle the setting and
highlight the desired option.
A L A R M D E L A Y
3 0 > 6 0 < 1 2 0 2 4 0 S
Push “SELECT” switch to save and increment the menu to the next alarm function.
Alarm Output 6 – User Assignable
Note – Alarm Output 6 can be configured for one of two HD Radio TM parameters, MC Available
Loss or Delay Bit Loss. MC Available Loss triggers whenever the multicast available bit is no
longer active, meaning that there was at least one multicast program being broadcast. If two
multicast programs are being broadcast and one is interrupted, the MC Available Loss alarm will
not activate because of the remaining multicast program. MC Available Loss is an option only in
FM.
• Highlight
desired MC Available - “MC-AV”, Delay Bit – “DLAY” or “OFF” option
using UP and DN switches to toggle the setting. Select desired function to be
alarmed and continue with alarm configuration menu; select “OFF” to set this monitor
alarm function to off.
