23
Record REC
Manually stop/start recording, working with direction keys
or numeral keys to select the recording channel.
Slow play Multiple slow play speeds or normal playback.
One-window monitor mode, click this button to display
assistant function: PTZ control and image color.
Backspace function: in numeral control or text control, press
it for 1.5seconds to delete the previous character before the
cursor.
In motion detection setup, working with Fn and direction
keys to realize setup.
In text mode, click it to switch between numeral, English
character(small/capitalized) and etc.
In HDD management interface, you can click it to switch
HDD record information and other information (Menu
prompt)
Assistant Fn
Realize other special functions.
Fast play Various fast speeds and normal playback.
Play previous
_
In playback mode, playback the previous video
Reverse/Pau
se
W
In normal playback or pause mode, click this button to
reverse
playback
In reverse playback, click this button to pause playback.
Play Next
f
In playback mode, playback the next video
In menu setup, go to down ward of the dropdown list.
Play/Pause f
In normal playback click this button to pause playback
In pause mode, click this button to resume playback.
Window
switch
Mult
Click it to switch one-window/multiple-window.
Shuttle(outer
ring)
In real-time monitor mode it works as left/right direction key.
Playback mode, counter clockwise to forward and clock wise
to backward.
Jog(inner
dial)
Up/down direction key.
Playback mode, turn the inner dial to realized frame by
frame playback. (Only applies to some special versions.)
USB port To connect USB storage device, USB mouse.
Remote
control
indication
light
ACT Remote control indication light
