110
Parameter Function
Keyboard: COM control protocol. You can use keyboard to
control DVR via COM.
Data Bit
The value ranges from 5 to 8.
Stop Bit
There are three options: 1/2.
Baud Bit You can select corresponding baud bit here.
Parity
There are four options: none/odd/even.
System default setup is:
z
Function: Console.
z Data bit: 8
z Stop bit: 1
z Baud bit: 115200
z Parity: None.
7.3.2.5 Network
Network interface is shown as in
X462H462H462H414H
Figure 7-32
X
.
Figure 7-32
Please refer to the following sheet for detailed information.
Parameter Function
Ethernet Please select the network card first.
DHCP Dynamically get IP address. You can get the device IP from
the DHCP server if you enabled this function.
TCP Port Default value is 37777.
HTTP Port Default value is 80.
