Configure Your FuzzyScan
51
PROGRAM
Wand/Laser Emulation Control
(F & L Series)
♦ ♦ ♦ ♦ Output Polarity, Signal State, Margin/Module Time ♦ ♦ ♦ ♦ F_DEFAULT
Family Code Selection P.C Parameter Selection Option Code
Output Polarity
SS
SS High level (5Vdc) on Bar (low level on Space)
Low level (0Vdc) on Bar (high level on Space)
Determine the output voltage level for both bar and space.
0
1
Initial Signal State
SS
SS High Level (5Vdc)
Low Level (0Vdc)
Determine the initial state of output voltage level.
0
1
Margin Time
SS
SS
SS
SS
SS
SS 10 msec.
15 msec.
20 msec.
25 msec.
30 msec.
50 msec. 0
1
2
3
4
5
Module Time
SS
SS
SS
SS Extremely short
Short
Medium
Long 0
1
2
3
Narrow/Wide Ratio
SS
SS
SS 1:2
1:2.5
1:3 0
1
2
