ESM-A50M

66 ESM-A50M Quick Installation Guide

3.6.3 Chipset Menu

This option configures the North bridge, North Bridge LVDS Config select and South

Bridge.

Item

Description

North Bridge

North Brideg Parameters.

North Bridge LVDS Config

Select

Specify INT15 options for LVDS.

South Brideg

South Bridge Parameters.
