REV-SA01 User ’s Manual
REV-SA01 User ’s Manual 7
1.5 System Specifications
System SMARC CPU Module socket: Accepts 82mm x 50mm SMARC Modules
Edge conn
DB9 x 1
DB15 x 1
HDMI x 1
Mini-USB x 1
USB Type A x 2
RJ45 x 2
SD Socket x 1
Backlight conn 5V, GND, ENBKL, VR, PWM
LVDS connector Hirose DF13-40DS-1.25, support 1 x 18/24bit LVDS
HDMI HDMI connector
VGA By Chrontel CH7055 (convert 24bit TTL signal to VGA)
CAN BUS CAN BUS connector x 2 (JST PHR-4) (CAN PHY TJA1041)
GPIO 10bit GPIO(pin header)
Audio
connector
Speaker out (L & R)
USB
USB Type A double deck x 1
USB signal for mPCIe (x1)
USB 2.0 pin header (x1)
Mini USB connector for USB OTG
SATA SATA connector x 1, 2pin wafer with 5V, 1A for SATA power
CAN Bus CAN bus pin header x 2
PCIe mPCIe socket x 1 (with PCIe x 1 & USB2.0 & USIM signal)
Ethernet RJ45 connector for GBE (with LED)
2
nd
Ethernet From RTL8111E
Camera
Connector
Camera connector with CSI-2 signals + I2C + GPIOx2 + 3.3V or 5V
Audio Codec WM8962, Line out, MIC in, Speaker out
RTC battery CR2032, RTC chip is ISL1208
Boot select 8 pin 2.0mm jumper
SD Socket SD Socket, support SDHC
G-Sensor MMA8451Q
LED Power on LED
