REV-SA01 User ’s Manual
REV-SA01 User ’s Manual 35
3.8 Display output application of IMX6
This section describes how to setup the display output for LVDS, HDMI, VGA of IMX6
module.
1. You can find the file of resolution setup of LVDS&VGA under the
directory ”..~/core/kernel/drivers/video/mxc”, for LVDS is ”ldb.c”, and for VGA is ”
mxc_lcdif.c”.
”ldb.c” ”mxc_lcdif.c”
2.
You need to fill the resolution parameter(.mode_str) on the file ”rev_sa01.c”
under ”~/core/kernel/arch/arm/mach-mx6/smarc/”, and the code of First Display is
alway in the upper block.
