EMS-CDV
4 EMS-CDV Quick Reference Guide
Chipset  IDT IDT89HPES5T5ZBBCG PCIe switch
Interface  5-Port/5-lane(for MI/Oe)
Display
Chipset  Cedarview integrated
Resolution  VGA: 1920x1200
Ethernet
Chipset  1 x Intel 82574L GbE controller
Ethernet Interface  10/100/1000 Base-Tx GbE compatible
Audio
Chipset  Realtek ALC892 HD codec
Audio Interface  Mic-In, Line-Inand Line-Out
Mechanical & Environmental
Power Requirement  +12 ~ +26Vdc
ACPI
 Single Power ATX Support S0, S3, S4, S5
 ACPI 3.0 Compliant
Power Mode  AT/ATX (ATX is The Default Setting)
Operating Temp.  -10°C ~ 60°C (w/ mSATA and 2.5 ” SSD), Ambient w/ Air Flow
Storage Temp.  -40°C ~ 75°C (-40 ~ 167°F)
Relative Humidity  0% ~ 90% Relative Humidity, Non-condensing
Vibration Protection
 With mSATA/ SSD : 5Grms, IEC 60068-2-64, Random, 10 ~ 500Hz,
1hr/axis
Shock Protection  With mSATA/ SDD : 50G, IEC 60068-2-27, Half Sine, 11ms
Certification  CE, FCC Class B
Dimension (W x H x D)  240mm x 170mm x 45mm
Weight  4.4 lbs (2 Kgs)
