Quick Reference Guide
EMS-CDV Quick Reference Guide 23
2.5 AUX-M01,AUX-M02 Jumper & Connector list
2.5.1 AUX-M01
Jumpers
Label Function Note
JRI3/4/5/6 COM 3/4/5/6 pin 9 signal select 3 x 2 header, pitch 2.00mm
Connectors
Label Function Note
USB1~2 USB connector 1~2
USB3 USB connector 3 5 x 1 wafer, pitch 2.00mm
JUSB3 USB connector 3 5 x 1 header, pitch 2.00mm
COM3~6 Serial port connector 3~6
2.5.2 AUX-M02
Connectors
Label Function Note
USB2~3 USB connector 2~3
LAN2~5 LAN connector 2~5
JLANLED LAN ACT/LNK/SPD LED 8 x 2 wafer, pitch 2.00mm
JLANMODE Normal/Bypass mode LED 6 x 2 wafer, pitch 2.00mm
.
