EPC-Series
6 EPC Series Quick Reference Guide
Model EPC-A50M
CPU
AMD® eOntario T40E (1.0GHz) CPU
AMD® eOntario T56N （1.6GHz） CPU
BIOS AMI 8 Mbit SPI BIOS
System Chipset AMD A50M Chipset
I/O Chip Winbond W83627DHG-P
System Memory One 204-pin DDR3 SODIMM up to 4GB DDR3-1066 SDRAM
SSD 1 x CompactFlash
Hard Disk 1 x 2.5” SATA HDD
mSATA 1xMini PCIe Card
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status
Monitor
Monitoring system temperature, voltage. Auto trotting control when CPU
overheats
External I/O
COM Port 2 x RS232; COM2 support RS-422/485 setting by BIOS
LAN Port 2 x RJ45
VGA/HDMI Port 1 x VGA; 1 x HDMI
Audio Port 1 x Mic in, 1 x Line-in and 1 x Line out
USB Port 4 x USB 2.0
SSD 1 x Type I/II CompactFlash socket
Expansions mSATA 1xMini PCIe Card (Internal)
Display
Chipset AMD Radeon 6250
Resolution VGA: 1920 x 1200 @ 60 Hz, HDMI: 1920 x 1200 @ 60 Hz
Multiple Display Two independent display combination of CRT, HDMI
Audio
AC97 Codec Realtek ALC892 supports 7.1-CH
Audio Interface Min In, Line in, Line out
Ethernet
LAN Chip 2x Realtek 8111E GigaLAN, supports Wake on LAN
Ethernet Interface 10/100/1000Base-Tx Fast Ethernet compatible
Mechanical &
Environmental
Power Requirement +12 ~ +26Vdc (Lockable DC Jack)
ACPI Single power ATX Support S0~S5 ACPI 2.0B
Power Type Single Power ATX
Operating Temp. 0 ~ 40°C (w/CF),ambient w/ air flow
Storage Temp. -20 ~ 75°C (-4~167°F)
