EPC-Series
4 EPC Series Quick Reference Guide
Model
EPC-945 EPC-AT270
CPU Supports 65nm Intel® µFC-PGA
478/µFC-BGA 479 Core
™
Duo/Core ™ Duo/Celeron® M CPU
Onboard Intel® Atom
™ N270
1.6GHz CPU
BIOS
Award 4 MBit Flash BIOS Award 8 MBit Flash BIOS
System Chipset
Intel® 945GME / ICH7-M Intel® 945GSE/ICH7-M
I/O Chipset
Winbond W83627HF-AW ITE 8712F
System Memory One 200-pin SODIMM supports up
to 2 GB DDR2 400/533/667
SDRAM
One 200-pin SODIMM supports up
to 2 GB DDR2 400/533 SDRAM
SSD
One CompactFlash Type I/II socket
Watchdog Timer
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
Display Intel® 945GME Integrated GMA
950 graphic
Intel® 945GSE Integrated
Audio
Realtek ALC883 supports 7.1-CH
Audio Realtek ALC655 supports
5.1-CH Audio
Ethernet
Dual Realtek RTL8111C PCI-E
Gigabit Ethernet, supports wake
on LAN (RTL8111B for Rev. A1)
Dual Marvell 88E8053 Gigabit
Ethternet, supports Wake on LAN
System Indicators
2 LED indicators show the power and HDD
Drive Bay Mounting kit for one 2.5” HDD(hidden)
Expansion
Interface ------- 1 x Mini PCIe
Serial Port 1 x RS-232 1x RS-232, 1xRS232/422/485
Ethernet Port 2 x RJ-45
WiFi Optional (USB Module)
DVI ------ 1 x DVI (Optional)
VGA / LCD Port 1 x DB-15
Audio Port Mic-in, Line-in, Line-out
USB Port 3 x USB 2.0 5 x USB 2.0
Mouse & KB 1 x PS/2 mini DIN 1 x PS/2 mini DIN (Optional)
Power Input 100 ~ 240 Vac / 50 ~ 60 Hz
Power Output +12 V
Operating
Temperature 0~40°C (32~104°F)
Storage
Temperature -20 to +75°C (-4~167°F)
Relative Humidity 5 to 90% @ 40°C (104°F), relative humidity, non-condensing
Dimension (W x D x
H) 7.0" x 5.6" x 2.0" (178 x 142 x 50
mm) 7.0" x 4.4" x 2.0" (178 x 112 x 50
mm)
Weight 2.7 lbs (1.2 Kgs)
Mounting VESA Compliance
