EPC-Series
10 EPC Series Quick Reference Guide
Connectors
Label Function Note
COM Serial port DB-9 male connector
CF CF Type I/II Socket with Ejector
DC-IN DC Power-in connector
DVI DVI connector (EPC-AT270 only)
HDD HDD indicator
HDMI HDMI connector (EPC-A50M only)
K/B Keyboard and PS/2 mouse connector
(EPC-LX800W only)
6-pin mini DIN
LAN1&2 2 x 10/100Base-Tx Ethernet connector RJ-45
LINE IN Line-in audio jack
LINE OUT Line-out audio jack (EPC-LX800W supported)
MIC IN Mic-in audio jack
PWR System power indicator
RESET Reset button
USB USB 2.0 connector 4 ports for EPC-A50M
5 ports for EPC-AT270
3 ports for EPC-945/LX800W
VGA CRT connector DB-15 female connector
