Quick Reference Guide
EPC Series Quick Reference Guide 5
Model EPC-LX800W
CPU
Onboard AMD Geode™ LX 800 @ 500MHz CPU
BIOS Award 4 MBit Flash BIOS
System Chipset
AMD Geode™ LX 800/ CS5536
I/O Chipset NuvoTon W83627DHG
System Memory One 200-pin SODIMM supports up to 1 GB DDR 333/400 SDRAM
SSD One CompactFlash Type I/II socket
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
Display AMD Geode LX800 with Integrated Graphics Engine
Audio Realtek ALC203 supports 2-CH Audio
Ethernet Dual Realtek RTL8101L 10/100 Rthernet
System Indicators 2 LED indicators show the power and HDD
Drive Bay
Mounting kit for one 2.5” HDD(hidden)
Expansion Interface N/A
Serial Port 2x RS-232
Ethernet Port 2 x RJ-45
WiFi Optional (USB Module)
VGA 1 x DB-15
Audio Port Line-out
USB Port 3 x USB 2.0
Mouse & KB 1 x PS/2 mini DIN
Power Input 100 ~ 240 Vac / 50 ~ 60 Hz
Power Output +5V
Operating Temperature -40 ~ 75°C (-40~167°F)
Storage Temperature -20 to +75°C (-4~167°F)
Relative Humidity 5 to 90% @ 40°C (104°F), relative humidity, non-condensing
Dimension (W x D x H) 7.0" x 4.4" x 2.0" (178 x 112 x 50 mm)
Weight 2.7 lbs (1.2 Kgs)
Mounting VESA Compliance
