Quick Reference Guide
EPC Series Quick Reference Guide 3
1.3 System Specifications
Model EPC-3711 EPC-CX700
CPU Onboard VIA Eden V4 1 GHz Onboard VIA Eden V4 500 MHz
BIOS Award 512 KB Flash BIOS
System Chipset VIA CN700/VT8251 VIA CX700M
I/O Chipset VIA VT1211
System Memory One 200-pin SODIMM supports up to 1 GB DDR2 400/533 SDRAM
SSD One CompactFlash Type I/II socket with ejector
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
Monitoring system and CPU temperature, voltage,
Auto throttling control when CPU overheats
Display VIA ProSavage CN700 integrated
2D/3D graphics engine VIA CX700M with integrated 2D
and 3D Graphics engine
Audio
VIA VT1616 supports 5.1 CH
Audio Realtek ALC883 supports 5.1 CH
Audio and 7.1 CH with SPDIF
Ethernet
Dual Realtek RTL8111B
1000Base-T Fast Ethernet
controllers
Dual Realtek RTL8101L
System Indicators 2 LED indicators show the power and HDD
COM Port 1 x RS-232, 1 x RS232/422/485, Setting by BIOS
Ethernet Port 2 x RJ-45
VGA / LCD Port 1 x DB-15
Audio Port Mic-in, Line-in, Line-out
USB Port 3 x USB 2.0 3 x USB 2.0
Mouse & KB 1 x PS/2 mini DIN
Power Input 100 ~ 240 Vac / 50 ~ 60 Hz
Power Output +5 Vdc / 8 A (40W)
Operating
Temperature
0~40°C (32~104°F)
Storage
Temperature
-20 to +75°C (-4~167°F)
Relative Humidity 5 to 90% @ 40°C (104°F), relative humidity, non-condensing
Dimension (W x D x
H)
7.0" x 4.4" x 2.0" (178 x 112 x 50 mm)
Weight 2.65 lbs (1.2 Kgs)
