User ’s Manual
EBM-A50M User ‟s Manual 59
3.6.2.8.3 Parallel port Configuration
Item Option Description
Parallel Port
Enabled,
Disabled
Enable or Disable parallel Port
(LPT/LPTE)
Change Settings
Auto
IO=378h; IRQ=5; DMA=3
IO=378h; IRQ=5,6,7,10,11,12: DMA=1,3;
IO=278h; IRQ=5,6,7,10,11,12: DMA=1,3;
IO=3BCh; IRQ=5,6,7,10,11,12: DMA=1,3;
IO=378h; DMA=1,3
IO=278h; DMA=1,3
IO=3BCh; DMA=1,3
Select an optional setting for
Super IO device.
Device Mode
STD Printer Mode
SPP Mode
EPP-1.9 and SPP Mode
EPP-1.7 and SPP Mode
ECP Mode
ECP and EPP 1.9 Mode
ECP and EPP 1.7 Mode
Change the Printer Port mode
