EBM-A50M User ‟s Manual 21
Connectors
Label Function Note
BAT-WB Battery connector 2 x 1 wafer, pitch 1.25mm
CFCARD Compact Flash card connector
COM1 Serial Port 1 connector D-sub 9 pin, male
CPU_FAN CPU fan connector 3 x 1 wafer, pitch 2.54mm
DIMM 204-pin DDR3 SODIMM socket
JAUDIO Audio connector 6 x 2 header, pitch 2.0mm
JBKL1 LCD Inverter connector 5 x 1 wafer, pitch 2.0mm
JBKL2 LCD Inverter connector 2 x 1 wafer, pitch 2.0mm
JCIR CIR connector (Optional) 5 x 1 wafer, pitch 2.0mm
JCOM2 Serial Port 2 connector 5 x 2 header, pitch 2.0mm
JCOM3 Serial Port 3 connector 5 x 2 header, pitch 2.0mm
JCOM4 Serial Port 4 connector 5 x 2 header, pitch 2.0mm
JCOM5 Serial Port 5 connector 5 x 2 header, pitch 2.0mm
JCOM6 Serial Port 6 connector 5 x 2 header, pitch 2.0mm
JDIO General purpose I/O connector 10 x 2 header, pitch 2.0mm
JKEY OSD for front panel key (Optional) 8 x 1 wafer, pitch 2.0mm
JLED LED indicator connector 7 x 2 header, pitch 2.0mm
JLVDS1 LVDS Connector (18bit) DIN 40-pin wafer, pitch 1.25mm
JLVDS2 LVDS Connector (DUAL 24bit) DIN 40-pin wafer, pitch 1.25mm
JLPC Low Pin Count Interface connector 7 x 2 header, pitch 2.0mm
JSPI SPI connector 4 x 2 header, pitch 2.0mm
JTOUCH Touch panel connector 5 x 1 header, pitch 2.54mm
JUSB1 USB connector 2&3 5 x 2 header, pitch 2.0mm
JUSB2 USB connector 4&5 5 x 2 header, pitch 2.0mm
JUSB3
USB connector 6&7
3.3V (Default) 5V is (Optional)
5 x 2 header, pitch 2.0mm
JVGA VGA connector 8 x 2 header, pitch 2.0mm
HDMI HDMI connector/ DISPLAY (Optional)
HP_OUT Audio line-out connector
LAN1 RJ-45 Ethernet 1
LAN2 RJ-45 Ethernet 2/ KB/MS (Optional)
LED LED indicator connector
MPCIE1 Mini-PCI connector 1
MPCIE2
Mini-PCI connector 2 (supports Optional
SIM CARD)
PRINT Optional LPT Connector
PWR1 Power connector
PWR2 Power connector (colay PWR3) 2 x 2 wafer, pitch 2.0mm
RSBTN Reset button
