EBM-A50M User ’s Manual
56 EBM-A50M User ‟s Manual
3.6.2.7.4 Serial Port 4 Configuration
3.6.2.7.4.1 Serial Port 1/2/3/4 Configuration
Item Option Description
Serial Port
Enabled,
Disabled Use the Serial port option to
enable or disable the serial port.
Change Settings
Auto
IO=3F8h; IRQ=3,
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12
Use the change Settings option to
change the serial port IO port
address and interrupt address.
