EBM-A50M User ’s Manual
58 EBM-A50M User ‟s Manual
Item Option Description
Serial Port
Enabled,
Disabled Use the Serial port option to
enable or disable the serial port.
Change Settings
Auto
IO=3F8h; IRQ=4,
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Use the change Settings option to
change the serial port IO port
address and interrupt address.
3.6.2.8.2 Serial Port 1 Configuration
Item Option Description
Serial Port
Enabled,
Disabled Use the Serial port option to
enable or disable the serial port.
Change Settings
Auto
IO=2F8h; IRQ=3,
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Use the change Settings option to
change the serial port IO port
address and interrupt address.
