EBM-A50M User ’s Manual
12 EBM-A50M User ‟s Manual
1.5 System Specifications
System
CPU
Onboard AMD Fusion Accelerated Dual-Core Processor T56N Dual Core 1.65GHz
CPU(18W), or optional T40E Dual Core 1.0GHz CPU(5~7W)
BIOS AMI 32M-bit SPI BIOS
System Chipset AMD A50M
I/O Chip Winbond W83627DHG-P
System Memory
Onboard 2G DDR3 1333 SDRAM, One 204-pin DDR3 SODIMM socket supports up
to 4GB DDR3 1333 SDRAM
SSD 1 x CompactFlash Type I/II socket
Watchdog Timer Reset: 1 sec.~65535 sec./min. and 1 sec. or 1 min./step
H/W Status
Monitor
Monitoring system temperature, voltage. Auto trotting control when CPU overheats
Expansion Mini-PCIe (Optional mSATA supported)
I/O
MIO
2 x SATA connector (7 pin)
2 x COM with pin header (one is RS-232 with selectable power by jumper, the other
is RS-232/422/485 by jumper)
LPC (7 x 2, pitch 2.00mm pin header ),
CIR (5 x 1, pitch 2.00mm Optional),
USB
8x USB 2.0 ports
(2 x Edge connector, 6 x pitch 2.0mm pin header)
JUSB3 support 3.3V (for low power USB module, ex:BT, RFID reader)
DIO 8-bit GPI, 8-bit GPO (PCA9555)
TPM NuvoTon WPCT200AA0WG (Optional)
Display
Chipset AMD Fusion Accelerated Processors
Resolution
CRT mode: T56N :2560 x 1600 @ 60 Hz
T40E:1920 x 1200 @ 60 Hz
LCD/Simultaneous mode : 1600 x 1200 @ 75 Hz
HDMI: 1920 x 1200 @ 60 Hz
Display port T56N :2560 x 1600 @ 60 Hz
T40E:1920 x 1200 @ 60 Hz
18-bit LVDS : 1400 x 1050 @ 60 Hz
Dual 24-bit LVDS : 1920 x 1200 @ 60 Hz
